Model

TCHTL1200-I

TCHTL1200-II

Power

1.5  KW

1.5KW

Quartz tube

(OD*Length mm)

25*600mm

50*600mm

Dimension

680X328X428

680X328X428

Max. Temp.

1200 ℃

Working temp.

≤ 1100 ℃

Heating element

Resistance wire

Heating rate

≤30 ℃/ Min ( suggest ≤15  ℃/ Min)

Heating zone length

200mm

Thermocouple

K type

Temp. controller

· Proportional–integral–derivative control (PID control) and auto-tune function

· Built-in Over Temperature and Thermocouple Failure Protection

· 30 segments programmed with ramping, cooling, and dwelling steps

· Default DB9 PC communication port

· Temperature accuracy: +/- 1°C

Controller accuracy

 +/- 1 ℃

Voltage

220V ,50/60HZ Single phase

Phase

Single phase

Warranty

One-year limited warranty (Consumable parts such as processing tubes, o-rings, and heating elements are not covered by the warranty)
