Inner Chamber Size

326mm(L) x 206mm(W) x 148mm(H)

Product Dimensions

        · Vacuum Box: 470mm(L) x 330mm(W) x 420mm(H)

        · Control Unit: 460mm(L) x 220mm(W) x 340mm(H)

Slot Trays (included)

        · Cylinder Slot Tray is working for the cylindrical cell type of battery samples. (96 slots)

        · Cylinder slot size: 20mm Dia. x 30mm Depth

        · Tray Dimension: 254mm L x 195mm W x 95mm H

Glovebox Compatible

        · Feedthrough is included to allow operation inside Glove Box

        · Such a Feedthrough ensures air-tightness of the glove box

        · Please use high purity inert gasses (Ar or N2), when operating in the glovebox, using Air Compressor when outside the glovebox.

       · Air Pressure Range: 0 - 1 Mpa (0 - 99 psi) Adjustable (Air Compressor is required, but not included. )

Vacuum Level

        · -90 kPa Max. (for second vacuum step, first vacuum step require -60kPa)

        · The vacuum pump is not included.

        · If you have your own pump with KF25 PORT, please order Barbed fitting to KF-25 Adapter at extra cost.

Power Supply

204-240 V, Single Phase 50/60Hz

Max. Power

50W

Compressed Air

≥0.6Mpa, no more than 1.5Mpa

Chamber Body

Aluminum case with the observation window

Vacuum Level

        · Vacuum condition remains stable, vacuum degree and vacuum circulation times can be set independently

        · Vacuum mode (once or twice) can be selected

        · Easy program setting for specific vacuum condition

         · -0.9 - 0 kPa adjustable (Vacuum pump is required, but not included. )

Air Inflation Time

0 - 99.99 sec

Vacuum Condition Hold Time

0 - 99.99 sec

Operation Temperature

 -20 to 40 ℃

Warranty

One year limited with lifetime support

Application Notes

        · Attention: High purity inert gasses and Vacuum Pump are necessary for operating the Vacuum Standing Box, please order them from your local store or the related products below

Net Weight

37.5 kg (83 lbs)
