Features:

• Frequency tracking, automatic frequency sweep tracking within 20KHz frequency range; Automatic energy compensation, can automatically work at the best frequency point and output point according to the fluidity of the sample;
• Adopt 7-inch color industrial touch screen control, all functions are integrated display; Scientific design, 10 groups of users store settings and can be directly operated on a single machine;
• Independent continuous pulse mode switch, with three modes of continuous, pulse, and timed continuous ultrasound; Exponential ultrasonic probe design, which far exceeds the output efficiency of traditional probe design and reduces the loss of the horn;
• Scientific design, 10 groups of users store settings and can be directly operated on a single machine;
• The equipment is equipped with a temperature sensor, which can test the temperature of samples in real time; Sample overload, over temperature and fault automatic alarm protection device.

Technical parameters:
Power supply: 85～260V/50-60Hz
Nominal frequency: 20KHz
Timer: 1S～99H can be setting
Power regulation: 1％—100％,1％ progressive
Temperature setting: 0—300℃，1℃ progressive
User program: 10 groups (can be set, can be stored, working status can be viewed in real time)
Pulser: working time, stop time, 1S～60min can be set
Operating mode: Pulse、Time、continuous
LCD screen: 7-inch color touch screen, resolution: 800×480
Operating language: English
Main interface display parameters: Ultrasonic output power, frequency, working mode, user group, setting key, equipment operating status, start/close, equipment operating parameter details key
Run interface display: Total running time, working time, stop time, user group, overload temperature, power output ratio, working mode, program save key
Host size: 440mm×248mm×236mm
Soundproof box size:
252mm×240mm×440mm
