Model |
TCHKF1200-I |
TCHKF1200-II |
TCHKF1200-III |
TCHKF1200-IV |
TCHKF1200-V |
|
Chamber size (DXWXH mm) |
300x200x120 |
300X200X200 |
300X250X250 |
400X300X300 |
500X400X400 |
|
Power (kw) |
2.5 |
4 |
5 |
9 |
15 |
|
Voltage (V) |
220 |
220 |
220 |
380 |
380 |
|
Max. Temp. |
1200℃ |
||||
|
Working temp. |
≤1100℃ |
||||
|
Heating elements |
Resistance wire |
||||
|
Heating rate |
≤30℃/min suggest heating rate：≤15℃/min |
||||
|
Thermocouple |
K type |
||||
|
Temp. controller |
PID automatic controller with 30 programmable segments for precise control of heating rate, cooling rate and dwell time. Built-in overheating & broken thermocouple protection. Over temperature protection and alarm allows for operation without attendant(s). +/- 1 ºC temperature accuracy. Three K-type thermocouples (one for each zone). Optional: For other kinds temperature controller we can designed according to your need. |
||||
|
Surface temp. |
≤45℃ |
||||
|
Warranty |
One-year limited warranty with lifetime support (Any damages caused by the use of corrosive and acidic gasses are not covered by the Warranty.) |
||||
