Microprocessor controller (with timing function)
Summary:
Provided for desiccation, torrefaction, wax-melting and sterilization in mining enterprises, laboratories and scientific research institutes
Features:
●Polished stainless-steel chamber
●Latest PID controller
●Uniform distribution of air temperature
●Forced-air convection
●Double Layer glass door, larger viewing window.
●Independent temperature-limiting alarm system ensures experiments run safely. (option)
●RS485 connector is option which can connect computer to record the parameters and the variations of temperature. (Option)
Specification:
Model
DHG-9030(A)
DHG-9070(A)
DHG-9140(A)
DHG-9240(A)
Voltage
AC220V 50HZ
Temp. range
RT+10～200℃/ RT+10～250℃
Temp. stability
±1.0℃
resolution
0.1℃
Temp. uniformity
±3%（testing point 100℃）
Ambient temp.
+5～40℃
Power
850W
1550W
2050W
2450W
Capacity
30L
80L
136L
220L
Inner chamber
W×D×H
340×320×320
450×400×450
550×450×550
600×500×750
Outside dimension
W×D×H
620×440×490
740×530×630
840×580×730
880×630×930
shelves
2 pieces (in the standard packing list)
Timing range
0～9999min
(mm)
300℃ Max. Drying Oven
Model
DHG-9015A
DHG-9035A
DHG-9055A
DHG-9075A
DHG-9145A
DHG-9245A
Voltage
AC220V 50HZ /60Hz
Temp. range
RT+10～300℃
Temp. stability
±1.0℃
resolution
0.1℃
Temp. uniformity
±3%(testing point is 100℃)
Ambient temp.
+5～40℃
Power
850W/850W
1100W
1550W
2050W
2450W
Capacity
16L/30L
50L
80L
136L
220L
Inner chamber
W×D×H
250×260×250
340×320×320
420×395×350
450×400×450
550×450×550
600×500×750
Outside dimension
W×D×H
530×370×420
620×440×490
720×530×520
740×530×630
840×580×730
880×630×930
shelves
2 pieces
Timing range
0～9999min
(mm)
Remark: polished stainless steel chamber is marked with an “A”, galvanized steel chamber isn’t marked with an “A”.
Options:
-
Intelligent programmable temperature controller (LCD)
-
Independent temperature-limiting
-
Alarm
-
Printer
-
RS485 connector
