Model |
NDJ-5T |
NDJ-9T |
NDJ-8T |
|
Control/display mode |
5 inches color touch screen |
||
|
speed(r/min) |
3/6/12/30/60 |
0.3/0.6/1.5/3/6/12/30/60 |
|
|
Measuring range mPa.s |
1~100,000 |
1~2,000,000 |
|
|
(Measuring 10 under low viscosity, equipped with 0 # rotor) |
|||
|
rotor |
1, 2, 3, 4#( standard) 0#( optional) |
||
|
Measurement error (Newtonian liquid) |
±1% |
±0.5% |
±1% |
|
Repetitive error (Newtonian liquid) |
±0.5% |
±0.25% |
±0. 5% |
|
Timing function |
standard |
||
|
Temp. measurement function |
The standard temperature sensor interface temperature sensor (selected) |
||
|
Automatic scanning function |
Automatic scanning and recommend the best combination of rotor and speed |
||
|
According to maximum measuring range |
Combination of rotor and speed automatically according to the selected viscosity range can be measured |
||
|
Should show shear/shear rate |
standard |
||
|
Automatic display kinematic viscosity |
Need to input the density of the sample |
||
|
Self-built measurement program |
Can save up to 30 groups (including the rotor, rotational speed, temperature, time, etc.) |
||
|
Save the measurement results |
Can save up to 30 sets of data (including viscosity, temperature, rotating speed of rotor, and the shear rate, Shear stress, time, density, kinematic viscosity, etc.) |
||
|
Viscosity curve |
Real-time display viscosity curve |
||
|
|
Data, curve can print (standard equipped with print interface, to choose and buy a printer) |
||
|
Data output interface |
standard |
||
|
Constant temp. parts |
Option (viscometer constant temperature trough, thermostatic cup, etc.) |
||
|
Working power supply |
Wide working voltage (110 v / 60 hz or 220 v / 50 hz) |
||
|
Overall dimensions |
300 × 300 × 450(mm) |
||
