Model |
TCH-A1400 |
|
Max. temperature |
1400C |
|
Working temp. |
≤1300C |
|
chamber size |
400*300*300mm |
|
power |
12KW |
|
Heating elements |
Sic rods covered by alumina tubes
|
|
thermocouple |
S type |
|
temperature controller |
· 30 programmable segments for precise control of heating rate, cooling rate and dwell time. · Built in PID Auto-Tune function with overheating & broken thermocouple broken protection. · Over temperature protection and alarm allows for operation without attendant(s). · +/- 1 ºC temperature accuracy. · One K-type thermocouple. · RS485 Communications Port.
|
|
certificate |
CE |
|
warranty |
One year limited warranty (Consumable parts such as the heaters not included) |
|
Atmosphere |
TCHGF14Q Max. Working temperature |
|
Air |
1400℃ |
|
Vacuum |
900-1100℃ |
|
N2 |
1270℃ |
|
H2 |
1100℃ |
|
Ar |
1300℃ |
