Model

TCHGF11Q-B-I

TCHGF11Q-B-II

TCHGF11Q-B-III

Power

4KW

9KW

16KW

Chamber size(mm)

280X180X180

380X280X280

480X380X380

Dimension(mm)

480X590X 712

580X690X930

680X 790X950

Voltage

220V, 50/60Hz

380V, 50/60Hz

Phase

Single phase

Three phase

Chamber material

Imported 310S stainless steel material(4mm thickness)

Max. temperature

900 ℃

Working temp.

≤800 ℃

Heating element

Resistance wire

Temp. controller

· Proportional–integral–derivative control (PID control) and auto-tune function

· 30 segments programmed with ramping, cooling and dwelling steps

· Built-in over-temperature alarm and thermocouple failure alarm

· +/- 1 ºC temperature control accuracy

· Default DB9 PC communication port

· MET Certified

Suggest heating rate

≤10 ℃/ Min

Thermocouple

K type

Vacuum degree

-0.1MPa in cold state

Warranty

1 year
