Model

TCHSJF1400-I

TCHSJF1400-III

Power

7KW

13KW

Chamber size (DXWXH)

200X200X200mm

300X300X300mm

Dimension (DXWXH)

700X700X1950mm

900X900X2200mm

Net weight

265Kg

310Kg

Voltage

220V, 50/60HZ

380V, 50/60HZ

Max. Temp.

1400°C max for an hour

Working temp.

≤1300°C

Thermocouple

S type

 Heating element

SiC rods

Heating rate

20°C/min , suggest ≤10°C/min

Lifting rate

420mm/ Min

Temp. controller

· PID automatic control and auto-tune function.

· 30 programmable segments for precise control.

· Built-in protection for the over-heating and broken thermocouple.

· Large digital control panel for easy operation.

Surface temp.

  ≤45℃

Warranty

One-year limited warranty with lifetime support

(Any damages caused by the use of corrosive and acidic gasses are not covered by the Warranty.)
