Model

TCHGF17Q-I

TCHGF17Q-II

TCHGF17Q-III

TCHGF17Q-IV

TCHGF17Q-V

Power

3 KW

5KW

7KW

9KW

13KW

Chamber size

(DXWXH mm)

160X150X150

200X200X200

300X200X200

300X250X250

400X300X300

Dimension (mm)

550X515X905

590X555X995

590X655X985

640X655X1035

690X715X1465

Voltage

220V, 50/60Hz

380V, 50/60Hz

Phase

Single phase

Three phase

Max. Temp.

1700 ℃

Working temp.

 ≤1600 ℃

Heating element

1800 type MoSi2 rods

Temp. controller

· PID automatic control and auto-tune function.

· 30 programmable segments for precise control.

· Built-in protection for the over-heating and broken thermocouple.

· Large digital control panel for easy operation.

· Temperature accuracy:  +/- 1 ℃

Heating rate

30 ℃/ Min Max. Suggest ≤10 ℃/ Min

Thermocouple

B type

Surface temp.

≤45 ℃

Vacuum pump

Optional parts, please order with extra cost

Warranty

1 year (not included the heaters)

Atmosphere

Max. Working temperature

NO2/CO2/O2/Air

1700℃

He/Ar/ Ne

1650℃

SO2

1600℃

Wet H2

1400℃

Dry H2

1350℃
