Material

Aluminum 99.99%

Length

48mm

Width

3mm

Thickness

0.09mm

Max. Loading Current

3A

Net Weight

46mg/pcs

Gross Wight

13.09g (Tabs with Box)

Application

1. Connect to cathode current collector as polymer battery positive terminal
2. Suggested Sealing Method: (parameter below may vary from case to case)
    - Soft type heat-sealing blade (Blade with rubber, see MSK-140)
    - 180-200C for upper blade
    - 160-180C for lower blade
    - 40PSI (0.3Mpa)
    - 3 seconds heating time
