Case Dimensions |
3.0 Thickness x 20 Width x 25 Length (mm) |
|
Net Weight |
32g (50 pcs) |
|
Layers from outside to inside(material in bracket) |
Polyamid (JIS Z1714): 0.025mm(+-0.0025mm)Adhesive (Polyester-polyurethane): 4-5g/m2Aluminum foil (JIS A8079,A8021): 0.040mm(+-0.004mm)Adhesive (Urethane-free Adhesive): 2-3g/m2 |
|
Thickness: |
111μm±11μm |
|
Surface Quality |
Matte finish |
|
Pinholes |
Subject to the applicable aluminum foil standard |
|
Impurity |
1mm or less in diameter |
|
Fish Eye |
2mm or less in diameter (clear), 1mm or less in diameter(colored) |
|
Moisture Vapor / O2 Transmission Rate |
200ppm / 5 years |
|
Laminate Strength |
Nylon/Al more than 2N/15mmAl/CPP more than 5N/15mm |
|
Heat Seal Strength |
More than 29.4N/15mm wide at 200℃ x 0.2Mpa x 2 sec |
|
Solvent Retention |
Less than 5mg/m2 |
|
Appearance |
Within the sample of the limit |
|
Slip Factor |
CPP/CPP less than 1.0 |
