Model |
TCH-HB1200 |
|
Furnace Construction |
· High purity fibrous alumina insulation for maximum energy saving
· Swing type door for easy and safe sample loading and unloading (with automatic power off when the door is opened) · Hybrid Furnace: One end flanged 2" quartz tube is included to perform tube flange application. Thermal block is included, which can be inserted to work as a muffle furnace. |
|
Temperature Calibrator |
The portable digital temperature calibrator |
|
Chamber Size |
· Size: 4"x4"x4" or 100x100x100 mm · Capacity: 65 cubic-inch or 1 liter |
|
Power |
1.2KW |
|
Voltage |
AC 220V 50/60 Hz |
|
Operating Temperature |
· 1000°C max for an hour |
|
Max. Heating Rate |
30 °C /min (suggest no more than 10℃/min) |
|
Temperature Controller
|
· PID automatic control and auto-tune function · 30 programmable segments for precise control · Built-in protection for the over-heating and broken thermocouple · Large digital control panel (48 x 96 mm) for easy operation |
|
Temperature Accuracy |
+/- 1 °C |
|
Heating Elements |
Fe-Cr-Al Alloy doped by Mo |
|
Thermocouple |
K type |
|
Warranty |
· One year limited warranty with lifetime support · ATTENTION: Any damages caused by the use of corrosive and acidic gases are not under the coverage of our One Year Limited Warranty. |
|
Compliance |
CE Certified |
