Model

TCHRVTL1200-II50

TCHRVTL1200-II60

TCHRVTL1200-II80

Power

1.5 KW

3.6KW

3.6KW

Tube size (mm)

Dia 50(OD) X600

   Dia60(OD)X1000

     Dia80(OD)X1000

Dimension (mm)

500X450X1800

550X500X1800

600X550X1800

Voltage

204-240V, 50/60HZ

Phase

single phase

Pull up systerm

 The controller controls the lifting speed, lifting stroke and speed of the lifting mechanism

Pulling speed: 0.1-2000μm / s

Lifting stroke: 0-100mm (can be customized according to customer needs)

rotary Speed: 0-40RPM

Lift down systerm

Crucible is supported by a quartz support

Pulling speed: 0.1μm / s ~ 2000μm / s

Lowering stroke: 0-150mm (can be customized according to customer needs)

Speed: 0-40RPM

Can be used for directional solidification
rotary Speed: 0-40RPM

Heating element

resistance wire

Temp. controller

1.High-quality high-purity alumina polycrystalline fiber curing furnace formed by vacuum suction filtration.

2, using Japanese technology molding.
3.The spacing and pitch of the resistance wires in the furnace are all arranged according to the best thermal technology in Japan, and the temperature field is simulated by the thermal software

Temp. accuracy

 +/- 1 ℃

SCR

106/16E made in German

Max. temp.

 1200 ℃

Working temp.

 1100 ℃

Heating rate

 ≤30 ℃/ Min (also can be designed according to your need)

Suggest heating rate

≤15  ℃/ Min

Thermocouple

K type

Heating zone length

205mm+205mm

Constant heating zone

100mm+100mm

Warranty

1 year not include quartz tube
