Overall Dimensions

· 12.5mm x 2.0 mm (Dia x Height)

Case Dimension

· Cathode: O.D. = 12.5mm, I.D. = 12.1mm

· Anode: O.D. = 12.0mm, I.D. = 10.0mm

Material

· Stainless Steel 304

· Polypropylene Sealing Gasket

Weight

0.1Oz (2.0 grams)or Ni

Note

· Spring for 1220 coin cell is not commercially available, you may cut 10 mm disk from 0.1 mm SS foil as spacer or Ni foil
