Model |
AE300L-P |
|
Working Voltage |
AC 220V 50/60Hz |
|
Input Power |
510W |
|
Output Power |
300W |
|
Rated Torsion |
22.1 N.cm |
|
Speed Control |
Controlled by seperated box |
|
Speed Range |
200-11000 rpm |
|
Max. Torque of Shearing Head |
22.0 N*cm |
|
Max. Stator Linear Velocity |
19 m/s |
|
Working Capacity(H2O) |
500-40000ml |
|
Material of Shearing Head |
Stainless Steel 304L |
|
Diameter of Shearing Head |
70 mm |
|
Standard Stator Size |
5/20/50 mm2 |
|
Min. Working Liquid Height Level |
50 mm |
|
Max. Working Liquid Height Level |
236 mm |
|
Max. Handling Viscosity |
8000 mPa.s |
|
Demension of Emulsifier |
360×260×760 mm |
|
Demension of Control Box |
240×120×150 mm |
|
Permissible Ambient Temperature |
≤40 ℃ |
|
Permissible Relative Humidity |
≤90% |
|
Net Weight |
13.8 kg |
|
Gross Weight |
15.0 kg |
